Professional FM/AM VW phantom antenna SNAP mast 20cm

Kod: 40753
Producent: KAWU

Category:Car antennas


Professional AM / FM roof antenna SNAP with high gain amplifier with original mast. The antenna is equivalent to the original antenna used for the first assembly. It performs AM / FM radio reception functions The antenna has a built-in high-quality SMD amplifier, which is located in the antenna foot. The antenna amplifier inside the antenna has Phantom power, which means that it is powered through the internal wire (antenna cable). The antenna works with any factory or non-factory radio with installation with SNAP connector. In the case of a non-factory radio, it is necessary to use antenna separator (which you will find here), which supplies power to the internal wire of the antenna cable. The antenna does not work with an external antenna amplifier. Specifications below.


Compatibility: You can mount antenna with following models:

  • VW New Beetle 1999-2010
  • VW Bora 1999-2005
  • VW Fox-EU od 2005
  • VW Fox-Africa 2004-2010
  • VW Golf 5 2004-2010
  • VW Golf 4 1998-2006
  • VW Lupo 1999-2006
  • VW Passat 1997-2005
  • VW Polo 2000-2010
  • AUDI A3 8L, A4 B5 (sedan, kombi),
  • AUDI A6 C5 (tylko kombi).

External antenna base thread: M14
Twisted mast: yes
Mast length: 20 cm
Cable length: 27.5 cm
SNAP connector - FM / AM signal,
