Peugeot Citroen Toyota car antenna FM/AM/GPS with amp

Kod: 40744
Producent: KAWU

Category:Car antennas

Description

car antenna FM / AM with amplifier for Peugeot ;Citroen; Toyota ; RG174 cable; 2 wires length 120cm

Specification

Compatibility:

  • CITROREN C2
  • CITROREN C3
  • CITROREN C4 II
  • CITROREN C4 PICASSO
  • CITROREN C5
  • CITROREN DS3
  • CITROREN DS4 II
  • PEUGEOT 207
  • PEUGEOT 207 SW
  • PEUGEOT 307
  • PEUGEOT 308
  • PEUGEOT 407
  • PEUGEOT 508
  • PEUGEOT RCZ 5008
  • PEUGEOT RCZ 3008
  • TOYOTA
Screwable mast: yes
Mast Lenght: 40 cm
Cables lenght : 120 cm

Frequency FM: 76 - 110 MHz,
Frequency AM: 525 - 1700 KHz,
Gain FM: +24 dB,
Gain AM: +20 dB,

Impedance AM/FM 75Ω

GPS band parameters: Frequency range 1575.42 MHz ± 1.02 MHz V.S.W.R 1.5: 1 Bandwidth> 10 MHz 50 Ω resistance 5dBic gain RHCP polarization GPS Low Noise Amplifier: Frequency range 1575.42 MHz ± 1.02 MHz DC voltage 3 - 5 V. Gain 28 ± 3 dB Cut-off ranges ≥25dB ​​(frequency range + 100MHz) ≥40dB (frequency range –100 MHz) V.S.W.R. output 1.5 NSR 1.2 DC 10.5 mA Summary parameters of GPS antenna and amplifier: Frequency range 1575.42 MHz ± 1.02 MHz V.S.W.R. output 1.5 Gain 28 ± 3dBic 50 Ω resistance Temp. work -25ºC ~ + 65ºC
