Description
roof antenna AM/FM ; mast lenght 16cm. Specification hereunder.
Specification
Antenna length: 162MM
Mast angle: 54 degree
Cable length: 135MM
Frequency: 535K-1705KHz(AM), 88-108MHz(FM)
Antenna gain: >8dB(AM), >18dB(FM)
Noise value: < 3.5dB
Output voltage standing wave ratio(VSWR)(amp): <3.5(AM), <2.5(FM)
Antenna voltage standing wave ratio (VSWR): <3.5 (FM)
Electric resistance: 75 ohm
Power supply: 12V 45mA-60mA
Connector: DIN
