Description
active DAB/FM antenna. DAB - Frequency range 174~237MHz / 1452~1492MHz Gain: 10 dB impedance: 50 Ohm AM / FM - Frequency range 525-1700Khz / 87,5 - 108 MHz Gain: 7 dB impendance 75 - 150 Ohm Dimmensions 45 x 45 x 300mm. Cable lenght 5m.
Specification
Active antenna DAB / AM/FM antenna with amplifier.
DAB - Frequency range B 174~237MHz / L-Band 1452~1492MHz
Gain: 10 dB
impedance: 50 Ohm
AM / FM - Frequency range 525-1700Khz / 87,5 - 108 MHz
Gain: 7 dB
impedance: 75 - 150 Ohm
Voltage: 12V
Cable lenght 5m with SMB (DAB) / DIN (AM/FM) connectors
Separate red wire for power supply
Dimensions 45 x 45 x 300mm.
